Description
Specifications
Dimensions: 4000 x 1750 x 2000 mm
Volume: 10 m³
Payload capacity: 8 tons
Standard colors: green, blue, red
The Abroll Skip Container compliant with DIN 30735 is designed for efficient waste collection and transportation in urban environments, construction sites and areas with limited access. Built for professional use, this container provides an excellent balance between durability, safety and operational efficiency. Made in UAE, the container is manufactured using modern production technology and high precision welding processes to ensure long service life and reliable performance.
The skip container DIN 30735 is compatible with vehicles equipped with multi-hook lifting systems (Absetzkipper), making it a practical solution for waste management companies, construction contractors and recycling operators.
What is a DIN 30735 Abroll Skip Container
The DIN 30735 standard regulates the dimensions, materials and safety requirements for skip containers designed for quick loading and unloading using specialized vehicles equipped with telescopic lifting arms and chain lifting systems. These containers are widely used in urban waste management, construction sites and industrial environments where compact and reliable containers are required.
Technical Characteristics of DIN 30735 Skip Containers
Manufactured according to DIN 30735:2016
Standard maximum width: 1520 mm
Typical volumes: between 2 m³ and 10 m³
Lifting hook height: approximately 800 mm
Distance between rollers: approximately 1300 mm
Tilt bearing pin diameter: approximately 30 mm
Materials Used
Floor made from 4 mm S235JR steel
Side walls made from 3 mm S235JR steel
Discharge wall made from 3 mm S235JR steel
Reinforcement profiles 60 x 40 mm
High strength steel lifting hook
Construction and Finishing
Continuous welding inside and outside for increased strength
Reinforced corners for improved durability
Heavy duty tilt bearings
Interior and exterior anti-corrosion primer coating
Exterior painting in customer selected RAL color
Optional DGUV 114-010 testing mark for export markets
Advantages of DIN 30735 Abroll Skip Containers
Compact dimensions suitable for restricted spaces
High maneuverability in urban environments
Robust construction for intensive daily use
Guaranteed compatibility with multi-hook lifting systems
Low maintenance requirements
Customization options available upon request
Applications
Municipal waste collection in urban areas
Construction and demolition sites
Recyclable material collection
Transport of small volumes of bulk materials
Municipal and industrial services
Abroll Skip Containers compliant with DIN 30735 provide a reliable and durable solution for waste management, construction and logistics operations requiring compact containers with high load capacity. Manufactured in the UAE, these containers ensure operational safety, compatibility with specialized vehicles and long term performance in demanding working environments.
