Description
Specifications
Dimensions: 3600 x 1720 x 1100 mm
Volume: 5 m³
Payload capacity: 7 tons
Standard colors: green, blue, red
The Abroll Skip Container compliant with DIN 30735-2 is a professional solution for waste collection and transportation in confined spaces and urban environments. Designed for compatibility with vehicles equipped with multi-hook lifting systems, this skip container provides high durability, easy maneuverability and safe operation.
Made in UAE and manufactured using modern production technology with continuous welding and strict quality control, the skip container is suitable for waste management companies, construction contractors, recycling operations and municipal service providers.
What is a DIN 30735-2 Abroll Skip Container
The DIN 30735-2 standard defines the dimensions, materials and safety requirements for skip containers used with Absetzkipper vehicles. These containers are designed for fast loading and unloading using hydraulic lifting arms and chain lifting systems.
Skip containers are divided into three main categories:
Asymmetric (A)
Symmetric (S)
Symmetric with lid (SD)
Technical Specifications DIN 30735-2 Skip Container
Standard: DIN 30735-2
Maximum width according to standard: 1520 mm
Fully welded construction inside and outside
Lifting hook compliant with DIN 30735
Materials Used
Floor made from 4 mm S235JR steel
Side walls made from 3 mm S235JR steel
Discharge wall made from 3 mm S235JR steel
Approximate Dimensions
Variable length optimized for maneuverability
Width optimized for easy access
Height designed for manual or mechanical loading
Finishing and Optional Features
Interior and exterior anti-corrosion primer coating
Exterior painting in customer selected RAL color
Hinged discharge door
End profile reinforcement
Tilt bearings for symmetric design
Reinforced corners
DGUV 114-010 testing mark for export markets
Advantages of DIN 30735-2 Abroll Skip Containers
Compact dimensions suitable for urban environments
High maneuverability in restricted spaces
Robust construction for intensive daily use
Guaranteed compatibility according to DIN 30735-2
Long service life and low maintenance requirements
Customization options available upon request
Applications
Municipal waste collection
Construction and demolition sites
Recyclable material collection
Transport of smaller material quantities
The Abroll Skip Container compliant with DIN 30735-2 is an efficient, safe and durable solution for waste management operations in urban and industrial environments. Manufactured in the UAE, this container ensures reliability, long service life and full compatibility with specialized skip loading vehicles.
