Description
Specifications
Dimensions: 5650 x 2500 x 1300 mm
Volume: 12 m³
Payload capacity: 15 tons
Tare weight: 1750 kg
Standard colors: green, blue, red
Roll-Off containers are manufactured using modern production technology including precision welding and advanced fabrication processes to ensure high structural strength, accuracy and durability. All roll-off containers are designed and produced according to the DIN 30722 standard, ensuring full compatibility with most trucks equipped with hook lift hydraulic systems.
The Roll-Off Container 12 m³ is suitable for waste management, transport of bulk materials, construction debris, grain and other industrial loads. The available container range covers volumes from approximately 4.6 m³ up to 40 m³, offering flexible solutions for various industries and operational requirements.
General Technical Characteristics of Roll-Off Containers
Manufactured according to DIN 30722-1 and DIN 30722-2 standards
Heavy duty frame constructed from INP 180 structural steel profiles
Floor made from steel plate thickness between 4 and 6 mm
Side and front walls made from steel plate thickness between 3 and 5 mm
Front hook lifting bar compliant with DIN 30722 standard
Rear steel rollers for easy sliding and loading on truck chassis
Rear double swing doors with secure locking system
Optional Hardox steel construction for increased wear resistance
Roll-Off System Functionality
Roll-off containers are designed to be quickly loaded and unloaded using trucks equipped with hydraulic hook lift systems. The vehicle can drop off a loaded container at the destination and immediately collect another container, optimizing operational time and reducing transport costs.
Advantages of Roll-Off Containers
High efficiency in handling and transport operations
Operational flexibility allowing one truck to service multiple containers
Robust construction for intensive use
Welding performed according to EN ISO 3834 quality standards
Long service life and resistance to mechanical stress
Customization options for dimensions, material thickness and locking systems
Applications
Municipal and industrial waste management
Recycling operations for metal, plastic, cardboard and glass
Construction and demolition transport including rubble and aggregates
Agriculture including grain, feed and bulk materials
Forestry and metal processing industries
Transport and logistics operations
Municipal services and public works
Standardization and Safety
The DIN 30722 standard regulates the dimensions, tolerances, hook position, guide rollers and strength requirements for roll-off containers. Compliance with this standard guarantees compatibility with lifting systems and ensures safe operation. Structural steel materials meet European quality standards and each container is inspected before delivery.
Why Choose Roll-Off Containers
Roll-off containers manufactured in the UAE combine modern engineering, advanced welding technology and strict quality control. The 12 m³ model offers a durable and efficient solution for companies that require reliable equipment for waste management, construction and industrial transport operations.
